QF® SD Automatic Blast Gate

QF SD Automatic Blast Gate

Nordfab
SKU:
3242-0300-100000
Availability:
Usually ships in 5 - 7 work days. Contact us for expediting.
$836.30
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Extremely robust Blast Gates to automatically balance the air flow and save money & energy.

Nordfab QF SD Automatic Blast Gates are operated by compressed air cylinders, controlled by electrically connected solenoid.

These Blast Gates are used as energy saving devices for industrial dust extraction where extraction is not always needed and where manual control needs to be eliminated. By connecting this Blast Gate to the power supply of any industrial machine, users can save energy and money by only exhausting air during machinery operation. If the machine is off, the gate stays closed, resulting in:

  • Increased suction at all other points in the system
  • Lower energy requirements for the fan
  • Less heated or cooled air exhausted out of the work area

This Blast Gate is built for years of continuous use in the most demanding conditions. A heavy duty cast aluminum body is encased in protective galvanized sheeting to safely shield fingers from moving parts. Efforts to test the gate “to failure” were abandoned after tens of thousands of cycles.

The long life and safety features of the SD Auto Gate are unmatched within its price range.

They are available in 3" - 24" diameters with QF rolled ends for easy connection to QF ductwork. The Reed Switch assembly is available as a spare part.

Product Features

  • 3" - 24" diameters
    • 3" - 8" have 1 cylinder
    • 9" - 24" have 2 cylinders
  • Very long durability
  • Extremely robust design
  • Automatic operation type
    • using compressed air cylinders
  • Saves energy & money
  • 120V control circuit
  • 75psi minimum air pressure
  • QF rolled edges
  • Quick, simple assembly



BISCO can assist customers in designing a blast-gate system, taking into account flow dynamics that will be affected by blast gates. While blast gates can be used effectively, they can also destroy the flow if not properly placed. Contact us for assistance.

Blast Gates are also available in these styles:

Product Specifications

Diameter 3 - 24 inch
Length 8.11" - 55.5"
Height 4.25" - 31.28"
Depth 6.3" - 42.4"
Weight 9.83lbs - 125lbs
Gauge ≤12":22ga, ≥14":20ga
Rating Max Temp: 120° F*
Material Galvanized
Duct Type Quick Fit Duct
Edge Rolled, 0.2" - 0.4"

Info & Guides

Questions & Answers

Do QF Clamps come with the blast gate? If not how many do I need to order?
Clamps do not come with this blast gate. As a rule, you will need one clamp per component ordered.

How do I connect to the end of an existing non QF system?
We offer a full line of adapters to connect to any existing pipe you might have.
