QF® Angle Flange Adapter

QF Angle Flange Adapter

Nordfab
SKU:
3250-0300-100000
Availability:
Usually ships in 5 - 7 work days. Contact us for expediting.
$68.00
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Angle Flange Adapter to quickly connect flanged ducting to QF ducting.

Nordfab’s QF Angle Flange Adapter is fitted with an industry standard Angle Flange on one end and a QF rolled edge at the other, allowing quick connection of QF duct pipe or fittings to flanged pipes or fittings. They're available in galvanized or stainless steel with 3" - 24" diameters. Flanges are retained with a Van Stone lip.

Custom hole patterns can be applied upon special request. Contact us to draw this out.

Quick-Fit has been used in a wide variety of applications, wherever dust collection or fine particulate transfer is required. Its QF rolled ends for use with QF clamps, allow quick assembly, disassembly and relocation. It clamps together in seconds without welds, bolts, screws, flanges, special tools, precise measurements or specialized skills. So, it cuts installation – and ducting related downtime – by more than 40% over traditional ductwork. See more benefits below.

Product Features

  • 3" - 24" diameters
  • Regular angle flange and QF rolled edge
  • Van Stone lip connection
  • Quick, simple assembly
  • Other diameters, gauges and materials available upon request

Product Specifications

Diameter 3 - 24 inch
Length 3,13-24":5", 4-12": 3.5"
Weight 1.4lbs - 30lbs
Gauge ≤12":22ga, ≥13":20ga
Material Galv, 304SS
Duct Type Quick Fit Duct
Edge Rolled, 0.2" - 0.4"

Info & Guides

Questions & Answers

What is the difference between an "angle flange" and a "flat flange"?
An Angle Flange is industry standard. A flat flange is a 1.5" wide flat piece of 3/16" sheet metal not drilled unless you supply a drawing for bolt hole locations.

Do QF Clamps come with the angle flange adapter? If not how many do I need to order?
Clamps do not come with the angle flange adapter. As a rule, you will need one clamp per component ordered.

How do I connect to the end of an existing non QF system?
We offer a full line of adapters including this angle flange adapter to connect to any existing pipe you might have.

When do I need to use stainless steel?
Stainless steel is used in FDA, chemical and high temperature applications.

Still have questions?
Browse our frequently asked questions page or contact us.

Discover the Benefits of Nordfab Ducting, "The World's Fastest Ducting™"

Nordfab Ducting, Quick Clamp

Fast Installation
Quick install and changes. Cuts install time by more than 45% compared to flanged ductwork.

Easy Connection
Simply clamp each piece together. No rivets, screws or welding are needed.

Strong & Leak Tight
High quality galvanized or stainless steel manufactured in the USA with laser welded seams.

Versatile
Use in a wide variety of applications, adapt to your existing ductwork and easily relocate.





Nordfab®, Quick-Fit®, and QF® are registered brands of Nordfab and are used here with Nordfab permission as we are a Nordfab Authorized Dealer.
