Flanged In Cut

Nordfab
SKU:
3823
$92.60
(No reviews yet)
Current Stock:
Adding to cart… The item has been added

In-Cut to cut into existing lines and connect to a Flanged Application at a slight angle.

Nordfab Flanged In Cut duct fittings are used to cut into existing duct lines to begin a flanged section in the ducting system. They utilize either 30° or 45° angles to effectively merge and ease the airflow into the new lines. Rotational Angle Flanges retained vanstone lip is standard.

In-cuts are also known as “saddle taps”. Saddle length and width = 3" all directions from Branch Tube C.

Available with QF ends in diameters up to 24" and other end types, sizes, materials and gauges upon request.

Product Features

  • 30° or 45° angles
  • Cuts into duct lines
  • For flanged end applications
  • Angle Flanges have Van Stone lips

Product Specifications

Diameter 3 - 24 inch
Gauge ≤12":22ga, ≥13":20ga
Material Galv, 304SS
Duct Type Flange
Edge Van Stone Lips

Info & Guides

Questions & Answers

How do I connect to the end of an existing non QF system?
We offer a full line of adapters to connect to any existing pipe you might have.

When do I need to use stainless steel?
Stainless steel is used in FDA, chemical and high temperature applications.

Still have questions?
Browse our frequently asked questions page or contact us.
