Insulated Air Handling Hose

Insulated Air Handling Hose

BISCO - Heat Flex
SKU:
4258
Availability:
Lead times vary. Contact us for in stock options.
$313.13 - $753.04
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Insulated Air Handling Hose.

Double ply, iron oxide red, silicone coated, fiberglass fabric hose reinforced with a spring steel wire helix makes up the inner layer. The outer layer is single ply, black neoprene coated, polyester fabric hose reinforced with a spring steel wire helix.

This hose is suited for air handling applications at low positive and low negative pressures. It's designed with good flexibility, 1-inch fiberglass insulation, insulated dryer hose, and excellent abrasion & chemical resistance. This design combines flexibility with minimal heat loss.

Key Features
  • Double ply inner layer & single ply outer layer
  • Coated fabric construction
  • Combines flexibility with minimal heat loss
    • Insulated dryer hose
    • Insulation
    • Good flexibility
  • Excellent abrasion & chemical resistance

Specifications
  • Size Range: 1" - 6"
  • Maximum Length: 12'
    • Cut charge on lengths < 12'
  • Colors: Iron Oxide red inner layer & black outer layer
  • Temperature Range
    • Inner Layer: -65°F to 550°F
      • intermittent to 600°
    • Outer Layer: -40°F to 250°F

Applications

Air

Aerospace

Info & Guides

Technical data information is shown on the second product image above. The data is based on 2 ft. straight lengths of hose at 72°. Contact us for more detailed data.
