Heat Stability Exhaust Hose

Heat Stability Exhaust Hose

BISCO - Reinforced Flex
SKU:
4265
Availability:
Lead times vary. Contact us for in stock options.
$48.47 - $193.70
(No reviews yet)
Current Stock:
Adding to cart… The item has been added
Description

Heat Stability Exhaust Hose.

Double ply red wire inserted fiberglass fabric hose with a silver heat resistant fiberglass liner mechanically crimped in a continuous process.

This hose is ideal for high temperature diesel exhaust applications and is great for reel & drop systems because it has excellent heat stability. It's constructed with fabric that is locked around a coated steel wire by a metal strip which acts as a wear strip and offers outstanding external abrasion resistance. It also has a negative pressure fan system with an ambient air inlet that's recommended in order to maximize the effectiveness and life of ducting. This makes the hose have good flexibility, durability, and flow characteristics.

This hose also has an inserted wire fabric and fiberglass liner that increases tensile strength for a longer life cycle.

Key Features
  • Double ply
  • Fabric hose
  • Fiberglass liner
    • Increased tensile strength
  • Fabric is locked by a metal strip
    • Metal strip acts as wear strip
  • Negative pressure fan system
  • Good flexibility, durability & flow characteristics

Specifications
  • Size Range: 4" - 18"
  • Maximum Length: 25'
    • Cut charge on lengths < 25'
  • Colors: Red with a silver liner
  • Temperature Range: -40°F to 750°F

Applications

Fumes

High Temperature, Paper Mills, Vehicle Exhaust Systems

Info & Guides

Technical data information is shown on the second product image above. The data is based on 2 ft. straight lengths of hose at 72°. Contact us for more detailed data.
