EcoBOSS Loop Box

BOSS Products
SKU:
EB-LB

Contact us for Pricing & Ordering. Give us a call at (800) 878-7309 or email mail@biscoair.com.

(No reviews yet)
Current Stock:
Description

A Simple, yet Powerful Addition to any Process Ventilation System with Energy Smart Operation

The Loop Box control panel regulates fan speed to deliver optimum CFM with energy savings up to 80%. It ensures additional efficiency by regulating fan speed dependent on varying filter pressure and resistance conditions. All Loop Box systems are remote start capable and designed to reduce energy consumption based on equipment utilization and spindle run time demand.

Added benefits include significant sound level reduction, increased filter life, maximum collection efficiency and fan capacity utilization.

Standard Features
  • NEMA 12 enclosure
  • Pressure transducer
  • SVD link light
  • Automatic start/stop of exhaust fan
  • Remote start/stop terminals
  • Terminals for connecting to:
    • Stand Alone Variable Speed Drive
    • Fire Control System
    • No Return Valve Monitoring Panel
    • Micro-Switch
    • Make-up Air Damper
    • Pulse Cleaning Control
    • Auxiliary Device Motor Starter Panel
  • UL labeled

Applications
  • Dust Collection
  • Mist Collection
  • Fume/Smoke Collection
  • Ambient Air Collection
  • Vehicle Exhaust


EcoBOSS Control Panels

EcoBOSS® Energy Management Control Systems deliver up to 80% reduction in kWh consumption for typical industrial ventilation systems. Boss Products engineers have spent years of research & testing to verify that the key to significant energy savings is to regulate fan performance capacity to deliver the suction volume based on spindle run time.

Advanced technology, systems engineering and modern components have been combined to create EcoBOSS® Energy Management Control systems. Simple to advanced levels of controls have been developed & field tested to optimize the function of industrial ventilation control applications.

EcoBOSS Energy Savings

The Fan Affinity Law

Typical industrial ventilation systems are designed to operate at full capacity. Extensive observation and case studies have shown that actual spindle run time rarely approaches 50% of full capacity during 90% of an average monthly production cycle!

EcoBOSS® Energy Management Systems have been designed to take full advantage of the Fan Affinity Law which clearly illustrates how an EcoBOSS® installation will work for you!

When a fan’s CFM volume is reduced by 50% the kWh consumption is reduced to 12.5% of full load.







For pricing, ordering or more information about the EcoBOSS® Loop Box, contact us.
